1626 Air Case

The 1626 Air Case is a large-format lightweight protective case from the Pelican Air series, built for professionals who need to transport substantial equipment loads without the weight of a full Protector case. It offers a spacious interior with the durability and protection the Air series is known for.

Ideal for:

• Full camera systems, lighting, and production accessories
• Multi-component drone kits and flight equipment
• AV, broadcast, and event production gear
• Industrial instruments and multi-piece field equipment sets

Why professionals choose this case:

• Large interior capacity — accommodates substantial equipment loads
• Air series construction keeps weight down without compromising protection
• Impact, dust, and water resistant shell with secure latching
• Suited to frequent travel, location work, and field deployment

Custom foam inserts available:

ProTech Customs designs and precision-cuts foam inserts to fit your exact equipment layout — turning a quality case into a complete, professional protection solution.

Need this case fitted to your equipment? Contact ProTech Customs to discuss custom foam inserts for a precise, professional fit-out.

Specifications

Exterior Dimensions
31.12 x 17.05 x 13.33" (79.04 x 43.31 x 33.86 cm)
Padlock Hole Diameter: 0.31" (0.79 cm)

Interior Dimensions
28.14 x 14.10 x 11.72" (71.48 x 35.81 x 29.77 cm)

Weight
With Foam: 18.10 lbs (8.21 kg)
Without Foam: 14.65 lbs (6.65 kg)

Measurements
Interior Volume: 2.69 ft³ (0.08 m³)
Lid Depth: 2.00" (5.08 cm)
Bottom Depth: 9.72" (24.69 cm)
Total Depth: 11.72" (29.77 cm)
Buoyancy: 185.32 lbs (84.06 kg)

Materials
Body: Proprietary Polypropylene Blend | Latch: ABS | O-Ring: EPDM | Purge Body: ABS | Purge Vent: Hi-Flow Gore-Tex 3 Micron Hydrophobic Non-Woven | Purge O-Ring: 70 Shore Nitrile

Temperature Range
Minimum: 0°F (-18°C) | Maximum: 140°F (60°C)
